New
HMB135
LF Driver
5 Inches
CAR
HOME
Magnet Material
Ceramic
Voice Coil Diameter
25 mm 1 in
Continuous Power Handling
150 W
Sensitivity
91 dB
Magnet Material
Ceramic
Voice Coil Diameter
25 mm 1 in
Continuous Power Handling
150 W
Sensitivity
91 dB
Specifiche
Nominal Diameter
130 mm (5 in)
Nominal Power Handling
75 W
Sensitivity
91 dB
Voice Coil Diameter
25 mm (1 in)
Former Material
Aluminium
Magnetic Gap Depth
5 mm (0.2 in)
Impedenza nominale
8 Ω
Continuous Power Handling
150 W
Frequency Range
130 Hz - 9000 Hz
Winding Material
CCAW
Winding Depth
8.5 mm (0.33 in)
Parametri
Fs
130 Hz
Qes
1.28
Qts
0.79
Sd
87 cm² (13.49 in²)
Xmax
3 mm (0.12 in)
Bl
4.51 Tm
d
105 mm (4.13 in)
Re
5.8 Ω
Qms
2.05
Vas
2.9 dm³ (0.1 ft³)
η0
0.49 %
Mms
5.5 g
Le
0.49 mH
EBP
102 Hz
Design
Surround Shape
Double Roll
Magnet Material
Ceramic
Recommended Loading
Sealed box
Suspension
Nomex Fabric
Cone Shape
Exponential
Recommended Enclosure
4 dm³ (0.14 ft³)
Connection Type
Fast-On
Cone Material
Doped cellulose fiber
Informazioni di montaggio e spedizione
Diametro totale
146 mm (5.75 in)
Baffle Cutout Diameter
117 mm (4.61 in)
Flange and Gasket Thickness
6 mm (0.24 in)
Shipping Units
6 pcs
Bolt Quantity
6 pcs
Bolt Circle Diameter
135.5 mm (5.33 in)
Depth
69 mm (2.72 in)
Net Weight
1.1 kg (2.43 lb)
Basket Material
Aluminum
Bolt Diameter
4.5 mm (0.18 in)
